Featires
>1/3" 1.3Megapixel CMOS
>25/30/50/60fps@720P
>High speed, long distance real-time transmission
>HD and standard definition switchable
>OSD Menu, control over coaxial cable
>Day/Night(ICR), AWB, AGC, BLC, 3D-DNR,
>8mm fixed lens (3.6 mm, 6mm, 12mm, 16mm optional)
>Max. IR LEDs length 50m, Smart IR
>IP66, DC12V
>Default with bracket (HFW2100D-B)
Technical Specifications
|
Model |
HAC-HFW2100DP |
HAC-HFW2100DN |
HAC-HFW2100DP-B |
HAC-HFW2100DN-B |
|
Camera |
|
Image Sensor |
1/3" 1.3Megapixel CMOS |
|
Effective Pixels |
1280(H)×960(V) |
|
Electronic Shutter |
4/25s~1/45,000s |
4/30~1/54,000s |
|
Video Frame Rate |
25/30/50/60fps@720P |
|
Synchronization |
Internal |
|
Min. Illumination |
0.01Lux@F1.2 (AGC ON), 0Lux IR LED on |
|
Video Output |
1-channel BNC HDCVI high definition video output/ CVBS standard definition video output (Can switch) |
|
Camera Features |
|
Max. IR LEDs Length |
50m, Smart IR |
|
Day/Night |
Auto(ICR) / Color / B/W |
|
Noise Reduction |
2D/3D |
|
OSD Menu |
Support |
|
Lens |
|
Focal length |
8mm fixed lens (3.6mm, 6mm,12mm,16mm optional) |
|
Mount Type |
M12 |
|
General |
|
Power Supply |
DC12V±10% |
|
Power Consumption |
Max 7.7W |
|
Working Environment |
-30°C~+60°C/ Less than 95%RH (no condensation) |
|
Transmission Distance |
Over 500m via 75-3 coaxial cable |
|
Ingress Protection |
IP66 |
|
Dimensions(W×D×H) |
200.2mm×89.1mm×80.4mm |
200.2mm×89.1mm×161.2mm |
|
Weight |
0.45kg |
0.58kg |
|
Others |
N/A |
Default: bracket included |  |
