ST-CW16
1.3Mp / 2Mp 25m IR HDCVI Dome Camera


Model No.
ST-CW16C
ST-CW16P
T-CW16S
ST-CW16V
ST-CW16N
Camera
Image Sensor
OV9750
AR0130
IMX225
OV2710
IMX322
DSP
HTC960
DH9801
HTC960
FH8530C
FH8530C
Image Resolution
960P
1080P
Effective Pixels
1280x960
1920x1080
1920x1080
TV System
PAL/NTSC
Electronic Shutter
1/25s~1/50,000s , 1/30s~1/60,000s
Sync System
Internal
Usable Illumination
0.01Lux
S/N Ratio
≥50dB
Scanning System
Progressive Scan
Video Output Mode
CVI(BNC)
Lens
Focus Length
Board Lens 3.6mm/F2.0
Focus Control
Fixed
Lens Type
Fixed
Pixels
2M Pixels
Auto Iris Support
NO
Night Vision
Infrared LED
¢5X30PCS
Infrared Distance
25M
IR Status
Under 10 Lux by CDS
IR Power On
CDS Auto Control
Camera Features
Day/Night
Auto (ICR) / Color / B&W
OSD Menu Language
No
White Balance
Auto
Gain Control
Auto
Noise Reduction
3D NR
2D NR
Picture Adjustment
No
OSD Support
No
General
Weatherproof Housing
YES, IP66
Anti-cut Bracket
YES, 3-Axis
Dual Voltage
NO
IR Cut Filter
YES
Heater
NO
Operation Temperature
-10℃ ~ +50℃ RH95% Max
Storage Temperature
-20℃ ~ +60℃ RH95% Max
Power Source
DC12V±10%, 500mA
Dimension
196(W)x89(H)x75(D)mm
Weight
880g
