1.3Mp / 2Mp 60m IR HDCVI Dome Camera
|
|
| |
|
Model No. |
ST-CW59C |
ST-CW59P |
T-CW59S |
ST-CW59V |
ST-CW59N |
|
Camera |
|
Image Sensor |
OV9750 |
AR0130 |
IMX225 |
OV2710 |
IMX322 |
|
DSP |
HTC960 |
DH9801 |
HTC960 |
FH8530C |
FH8530C |
|
Image Resolution |
960P |
1080P |
|
Effective Pixels |
1280x960 |
1920x1080 |
1920x1080 |
|
TV System |
PAL/NTSC |
|
Electronic Shutter |
1/25s~1/50,000s , 1/30s~1/60,000s |
|
Sync System |
Internal |
|
Usable Illumination |
0.01Lux |
|
S/N Ratio |
≥50dB |
|
Scanning System |
Progressive Scan |
|
Video Output Mode |
CVI(BNC) |
|
Lens |
|
Focus Length |
2.8-12mm |
|
Focus Control |
Manual |
|
Lens Type |
Manual |
|
Pixels |
2M Pixels |
|
Auto Iris Support |
NO |
|
Night Vision |
|
Infrared LED |
￠5X72PCS |
|
Infrared Distance |
60M |
|
IR Status |
Under 10 Lux by CDS |
|
IR Power On |
CDS Auto Control |
|
Camera Features |
|
Day/Night |
Auto (ICR) / Color / B&W |
|
OSD Menu Language |
No |
|
White Balance |
Auto |
|
Gain Control |
Auto |
|
Noise Reduction |
3D NR |
2D NR |
|
Picture Adjustment |
No |
|
OSD Support |
No |
|
General |
|
Weatherproof Housing |
YES, IP66 |
|
Anti-cut Bracket |
YES, 3-Axis |
|
Dual Voltage |
NO |
|
IR Cut Filter |
YES |
|
Heater |
NO |
|
Operation Temperature |
-10℃ ~ +50℃ RH95% Max |
|
Storage Temperature |
-20℃ ~ +60℃ RH95% Max |
|
Power Source |
DC12V±10%,1000mA |
|
Dimension |
260(W)x98(H)x85(D)mm |
|
Weight |
1.7kg |  |
| |
|
|
|
|
