Features
>Up to 24/32 cameras with 1080p realtime preview
>H.264 dual-stream video compression
>All channel 960H realtime recording
>HDMI/VGA/TV/Spot simultaneous video output
>All channel simultaneous realtime playback, GRID interface & smart search
>3D intelligent positioning with Dahua PTZ dome camera
>Support 8 SATA HDDs up to 32TB, 1 eSATA up to 16TB,4 USB2.0
>Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Specifications
|
Model |
DVR7824S |
DVR7832S |
|
System |
|
Main Processor |
Embedded processor |
|
Operating System |
Embedded LINUX |
|
Video |
|
Input |
24 channel, BNC |
32 channel, BNC |
|
Standard |
NTSC(525Line, 60f/s), PAL(625Line, 50f/s) |
|
Audio |
|
Input |
16 channel, BNC |
|
Output |
1 channel, BNC |
|
Two-way Talk |
1 channel Input ,1 channel Output, BNC |
|
Display |
|
Interface |
2 HDMI, 1 VGA, 1 TV, 1 Spot |
|
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 |
|
Display Split |
1/4/8/9/16/25 |
1/4/8/9/16/25/36 |
|
Privacy Masking |
4 rectangular zones (each camera) |
|
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
|
Recording |
|
Video/Audio Compression |
H.264/G.711 |
|
Resolution |
960H(960×576/960×480)/D1/4CIF(704×576/704×480)/
HD1(352×576/352×480)/2CIF(704×288/704×240)
CIF(352x288/352×240) / QCIF(176×144/176×120) |
|
Record Rate |
Main Stream: |
960H/D1/HD1/2CIF/CIF(1~25/30fps) |
|
Extra Stream |
CIF/QCIF(1~25/30fps) |
|
Bit Rate |
48~3072Kb/s |
|
Record Mode |
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
|
Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
|
Video Detection & Alarm |
|
Trigger Events |
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot,
Buzzer & Screen tips |
|
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
|
Alarm Input |
16 channel |
|
Alarm Output |
6 channel |
|
Playback & Backup |
|
Sync Playback |
1/4/9/16 |
|
Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
|
Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file,
Previous file, Next camera, Previous camera, Full screen,
Repeat, Shuffle, Backup selection, Digital zoom |
|
Backup Mode |
USB Device/Network/Internal SATA burner/eSATA Device |
|
Network |
|
Ethernet |
2RJ-45 port (10/100/1000M) |
|
Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server |
|
Max. User Access |
128 users |
|
Smart Phone |
iPhone, iPad, Android, Windows Phone |
|
Storage |
|
Internal HDD |
8 SATA ports, up to 32TB |
|
External HDD |
1 eSATA port, up to 16TB |
|
Auxiliary Interface |
|
USB Interface |
4 ports(2 Rear), USB2.0 |
|
RS232 |
1 port, For PC communication & Keyboard |
|
RS485 |
1 port, For PTZ control |
|
General |
|
Power Supply |
AC100~240V,50/60Hz |
|
Power Consumption |
40W(without HDD) |
|
Working Environment |
-10 ~+55°C / 10~90%RH / 86~106kpa |
|
Dimension(W×D×H) |
2U, 440mm×460mm×89mm |
|
Weight |
6.5KG(without HDD) |  |
