Features
>Up to 8/16/32 channel with 1080p realtime live view
>H.264/MJPEG decoding & H.264 dual-stream encoding
>IP: Max 240fps@1080p, 480fps@720p;
>Analog: 16 channel@960H(960× 576/960× 480) realtime recording
>HDMI / VGA / TV/ Spot simultaneous video output
>All channel synchronous realtime playback, GRID interface & smart search
>Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon,
>CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech ,and etc.
>ONVIF Version 2.0 conformance
>Auto IP address acquisition by IP Search function
>3D intelligent positioning with Dahua PTZ dome camera
>Support 8 SATA HDDs up to 32TB, 1 eSATA up to 16TB, 4 USB2.0
>Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Technical Specifications
|
Model |
DVR7804S-U |
DVR7808S-U |
DVR7816S-U |
|
System |
|
Main Processor |
Dual-core embedded processor |
|
Operating System |
Embedded LINUX |
|
Video |
|
IP Video Input |
4 channel |
8 channel |
16 channel |
|
Analog Input |
4 channel, BNC |
8 channel, BNC |
16 channel, BNC |
|
Analog Video Standard |
NTSC(525Line, 60f/s), PAL(625Line, 50f/s) , Effio 960H camera |
|
Loop Output |
4 channel, BNC |
8 channel, BNC |
16 channel, BNC |
|
Audio |
|
Input |
4 channel, BNC |
8 channel, BNC |
16 channel, BNC |
|
Output |
1 channel, BNC |
|
Two-way Talk |
1 channel Input, 1 channel Output, BNC |
|
Display |
|
Interface |
2 HDMI, 1 VGA, 1 TV, 1 Spot, BNC |
|
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 |
|
Display Split |
1/4/8 |
1/4/8/9/16 |
1/4/8/9/16/25/36 |
|
Privacy Masking |
4 rectangular zones (each camera) |
|
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
|
Recording |
|
Video/Audio Compression |
H.264 / MJPEG(IP) / G.711 |
|
Resolution |
1080P(1920×1080) / 720P(1280×720) / 960H(960×576/960×480) / D1/4CIF(704×576/704×480) / HD1(352×576/352×480) / 2CIF(704×288/704×240) / CIF(352×288/352×240) /QCIF(176×144/176×120) |
|
Record Rate |
IP |
Max 480fps@720P / 240fps@1080P |
|
Analog |
All channel@960H (25/30fps) |
|
Bit Rate |
IP: 48~8192 Kb/s, Analog: 48~4096Kb/s |
|
Record Mode |
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
|
Record Interval |
1~120 min. (default: 60 min.), Pre-record: 1~30 sec., Post-record: 10~300 sec. |
|
Video Detection & Alarm |
|
Trigger Event |
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips |
|
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
|
Alarm Input |
4 channel |
8 channel |
16 channel |
|
Relay Output |
6 channel |
|
Playback & Backup |
|
Sync Playback |
1/4 |
1/4/9 |
1/4/9/16 |
|
Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
|
Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
|
Backup Mode |
USB Device / eSATA Device / Internal SATA burner/ Network |
|
Network |
|
Ethernet |
2 RJ-45 port (10/100M/1000M) |
|
Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.) |
|
Max. User Access |
128 users |
|
Smart Phone |
iPhone, iPad, Android, Windows Phone |
|
Storage |
|
Internal HDD |
8 SATA ports (8HDDs or 6HDDs+1CD/DVD-RW), up to 32TB |
|
External HDD |
1 eSATA port (Max 4 SATA HDDs), up to 16TB |
|
Auxiliary Interface |
|
USB Interface |
4 ports (2 Rear), USB2.0 |
|
RS232 |
1 port, For PC communication & Keyboard |
|
RS485 |
1 port, For PTZ control |
|
General |
|
Power Supply |
AC 100~240 V, 50/60 Hz |
|
Power Consumption |
40W |
|
Working Environment |
-10 ~+55°C / 10~90%RH / 86~106kpa |
|
Dimension
(W×D×H) |
2U, 440mm×460mm×89mm |
|
Weight |
6.5KG(without HDD) |  |
