Features
>Up to 4/8 cameras with 1080p realtime preview
>H.264 dual-stream video compression
>HCVR5104/5108HC: All channel 720P
>HDMI / VGA simultaneous video output
>4 channel synchronous realtime playback, GRID interface & smart search
>3D intelligent positioning with Dahua PTZ dome camera
>Support 1 SATA HDD up to 4TB, 2 USB2.0
>Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Technical Specifications
Model |
HCVR5104HC |
HCVR5108HC |
System |
Main Processor |
Embedded processor |
Operating System |
Embedded LINUX |
Video |
Input |
4 channel, BNC |
8 channel, BNC |
Standard |
NTSC(525Line, 60f/s), PAL(625Line, 50f/s) |
Display |
Interface |
1 HDMI, 1 VGA, |
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768, 800×600 |
Display Split |
1/4 |
1/4/8 |
Privacy Masking |
4 rectangular zones (each camera) |
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Recording |
Video/Audio Compression |
H.264 / G.711 |
Resolution |
720P(1280×720/1280×600)/960H(960×576/960×480)/D1/4CIF(704×576/704×480) / CIF(352×288/352×240) / QCIF(176×144/176×120) |
Record Rate |
Main Stream: |
720P/960H/D1/HD1/2CIF/CIF(1~25/30fps) |
Extra Stream |
CIF/QCIF(1~25/30fps) |
Bit Rate |
48~6144Kb/s |
Record Mode |
Manual, Schedule(Regular(Continuous), MD), Stop |
Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Video Detection |
Trigger Events |
Recording, PTZ, Tour, Video Push, Email, FTP, Spot, Buzzer & Screen tips |
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
Playback & Backup |
Sync Playback |
1/4 |
1/4/8 |
Search Mode |
Time/Date, MD & Exact search (accurate to second) |
Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
Backup Mode |
USB Device / Network |
Network |
Ethernet |
RJ-45 port (10/100M) |
Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter |
Max. User Access |
128 users |
Smart Phone |
iPhone, iPad, Android, Windows Phone |
Storage |
Internal HDD |
1 SATA port, up to 4TB |
Auxiliary Interface |
USB Interface |
2 ports(2 Rear), USB2.0 |
General |
Power Supply |
DC12V/2A |
Power Consumption |
10W(without HDD) |
Working Environment |
-10 ~+55°C / 10~90%RH / 86~106kpa |
Dimension(W×D×H) |
Mini 1U, 325mm×245mm×45mm |
Weight |
1.5KG(without HDD) | |
