Overview
• 8/16/32ch IP camera inputs • 1/1ch Mic in/out • 8/16/32ch@1080p • Compatible with 5Mp, 3Mp, 1080p, 720p, D1 and etc. • HDMI, VGA output up to 1080p, 1 TV • 8/16/16ch alarm in & 3/6/6ch relay out, RS485, RS232 • 4 SATA, 1 eSATA , 3 USB, 1 RJ45(1000Mbps) • Incoming bandwidth: 160Mbps
• Support plug & play, 8 PoE Ports
Features
> Up to 8/16/32 channel with 1080p realtime live view
> H.264/MJPEG dual codec decoding
> Up to 5Mp resolution
> Max 160Mbps incoming bandwidth
> HDMI / VGA simultaneous video output
> 8/16/32 channel synchronous realtime preview, GRID interface
> Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon,
CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech and etc.
> ONVIF Version 2.0 conformance
> 3D intelligent positioning with Dahua PTZ camera
> Support 4 SATA HDDs up to 16TB, 1 eSATA up to 16TB, 3 USB2.0
> Support IPC UPnP, 8 PoE ports
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Technical Spcifications
|
Model |
NVR5408-8P |
NVR5416-8P |
NVR5432-8P |
|
System |
|
Main Processor |
Dual-core embedded processor |
|
Operating System |
Embedded LINUX |
|
Video & Audio |
|
IP Camera Input |
8 channel |
16 channel |
32 channel |
|
Two-way Talk |
1 channel Input, 1 channel Output, BNC |
|
Display |
|
Interface |
1 HDMI, 1 VGA, 1TV |
|
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 & etc. |
|
Display Split |
1/4/8/9 |
1/4/8/9/16 |
1/4/8/9/16/25/36 |
|
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
|
Recording |
|
Compression |
H.264 / MJPEG |
|
Resolution |
5Mp(2560×1920) / 3Mp(2048×1536) / 1080p(1920×1080) / 720p(1280×720) / D1(704×576/704×480) & etc. |
|
Record Rate |
Max 128Mbps ( eg. 16ch 5Mp@8Mbps, 16ch 1080p@8Mbps & etc.) |
|
Bit Rate |
48~ 8192kbps |
|
Record Mode |
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
|
Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
|
Video Detection & Alarm |
|
Trigger Events |
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Screen tips |
|
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
|
Alarm Input |
8 channel |
16 channel |
16 channel |
|
Relay Output |
3 channel |
6 channel |
|
Playback & Backup |
|
Sync Playback |
1/4/9 |
1/4/9/16 |
1/4/9/16 |
|
Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
|
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
|
Backup Mode |
USB Device / eSATA Device / Internal SATA burner/ Network |
|
Network |
|
Ethernet |
1 RJ-45 port (10/100M/1000Mbps) |
|
Network Function |
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.) |
|
Max. User Access |
20 users |
|
Smart Phone |
iPhone, iPad, Android, Windows Phone |
|
Storage |
|
Internal HDD |
4 SATA ports (4HDDs or 3HDDs+1CD/DVD-RW), up to 16TB, Raid (redundancy) |
|
External HDD |
1 eSATA port (Max 4 SATA HDDs), up to 16TB |
|
Auxiliary Interface |
|
USB |
3 ports (2 Rear), USB2.0 |
|
RS232 |
1 port, For PC communication & Keyboard |
|
RS485 |
1 port, For PTZ control |
|
General |
|
Power Supply |
AC 100~240V, 50/60 Hz |
|
Power Consumption |
NVR: 40W (without HDD)
PoE port: Max 15W (each) |
|
Working Environment |
-10 ~+55°C / 10~90%RH / 86~106kpa |
|
Dimension (W×D×H) |
1.5U, 440mm × 460mm × 68mm |
|
Weight |
5KG (without HDD) |  |
