Features
>Up to 8/16/32 channel IP camera input
>H.265/H.264/MJPEG dual codec decoding
>Max 256Mbps incoming bandwidth
>Up to 8ch@1080P(4ch@H.265+4ch@H.264) realtime live-view
>Up to 12Mp resolution preview&playback
>HDMI/VGA simultaneous video output
>8/16 channel synchronous realtime playback, GRID interface
>Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon,
CP Plus, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek and etc.
>ONVIF Version 2.4 conformance
>3D intelligent positioning with Dahua PTZ camera
>Support 2 SATA HDDs up to 12TB, 2 USB(1 USB3.0)
>Support IPC UPnP, 8PoE ports (for -8P model)
>Support P2P, QR code scan & add
>Multiple network monitoring: Web viewer, CMS(DSS/Smart PSS) & Smart Phone(DMSS)
Specifications
|
Model |
NVR4208-4K |
NVR4216-4K |
NVR4232-4K |
|
NVR4208-8P-4K |
NVR4216-8P-4K |
NVR4232-8P-4K |
|
System |
|
Main Processor |
Dual-core embedded processor |
|
Operating System |
Embedded LINUX |
|
Video& Audio |
|
IP Camera Input |
8 channel |
16 channel |
32 channel |
|
Two-way Talk |
1channel Input, 1channel Output, RCA |
|
Display |
|
Interface |
1 HDMI , 1 VGA |
|
Resolution |
3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768 |
|
Display Split |
1/4/8/9 |
1/4/8/9/16 |
1/4/8/9/16 |
|
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
|
Recording |
|
Compression |
H.265/H.264/MJPEG |
|
Resolution |
12Mp, 8Mp, 6Mp, 5Mp, 3Mp, 1080P, 1.3Mp, 720P & etc. |
|
Record Rate |
192Mbps |
|
Bit Rate |
1~ 20Mbps |
|
Record Mode |
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
|
Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
|
Video Detection & Alarm |
|
Trigger Events |
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips |
|
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
|
Alarm Input |
8 channel |
|
Relay Output |
3 channel |
|
Playback & Backup |
|
Sync Playback |
1/4/9 |
1/4/9/16 |
1/4/9/16 |
|
Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
|
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
|
Backup Mode |
USB Device/Network/Internal SATA burner |
|
Network |
|
Ethernet |
1 RJ-45 port (10/100/1000Mbps) |
|
PoE |
8 ports (IEEE802.3at/af) (for -8P model) |
|
Network Function |
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.) |
|
Max. User Access |
128 users |
|
Smart Phone |
iPhone, iPad, Android, Windows Phone |
|
Storage |
|
Internal HDD |
2 SATA III ports, up to 12TB |
|
Auxiliary Interface |
|
USB |
2 ports (1 Rear USB3.0, 1 Front USB2.0) |
|
RS232 |
1 port, For PC communication& Keyboard |
|
RS485 |
1 port, For PTZ control |
|
General |
|
Power Supply |
Single, DC12V/4A(for normal model) |
|
Single, AC 100~240V, 50/60 Hz(for -8P model) |
|
Power Consumption |
NVR: 8.7W for normal model(without HDD), 15.2W for PoE model(without HDD) |
|
PoE: Max 25.5W for single port(for -8P model),120W in total |
|
Working Environment |
-10°C~+55°C/10%~90%RH/86~106kpa |
|
Dimension
(W×D×H) |
1U, 375mm×275mm×56mm |
|
Weight |
1.65KG for normal model(without HDD), 2.65KG for PoE model(without HDD) |  |
