Features
>Up to 4 channel 1080P cameras realtime live view
> H.264/MJPEG dual codec decoding
> 100/120fps@1080p preview & recording
> HDMI / VGA / LCD simultaneous video output
> All channel synchronous realtime playback, GRID interface
> ONVIF Version 2.0 conformance
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 3D intelligent positioning with Dahua PTZ camera
> Support camera and temperature controller Info Overlay
> Support Volume Information Overlay
> Support One-press Write / Stop
> Support PIP live view display
> CD can be replaced during operation and the new CD can proceed from the spot where the previous CD stopped
> Marks can be created during writing to improve search efficiency in playback
> Support Burner Status Check
> Support 1 SATA HDD, 2 DVD, 3 USB2.0
> Built-in 13.3-inch touch screen LCD
Specifications
|
Model |
NVR0404FD-M |
|
System |
|
Main Processor |
Dual-core embedded processor |
|
Operating System |
Embedded LINUX |
|
Video |
|
IP Camera Input |
4 channel (Support PoE) |
|
Audio |
|
Video input |
2 channel(aviation port) |
|
Video output |
1 channel(standard 3.5mm audio port) |
|
Two-way Talk |
1 channel Input, 1 channel Output(standard 3.5mm audio port) |
|
Display |
|
Interface |
1HDMI, 1 VGA, 1 LCD |
|
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 |
|
Display Split |
1/4 / PIP |
|
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
|
Recording |
|
Compression |
H.264 / G.711 |
|
Resolution |
1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480) |
|
Record Rate |
100/120fps@1080P |
|
Bit Rate |
48 ~ 8192kbps |
|
Record Mode |
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
|
Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
|
Video Detection & Alarm |
|
Trigger Events |
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Screen tips |
|
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
|
Alarm Input |
2 channel |
|
Relay Output |
2 channel |
|
Playback & Backup |
|
Sync Playback |
1/4 |
|
Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
|
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
|
Backup Mode |
USB Device /Network |
|
Network |
|
Ethernet |
1 RJ-45 ports (10/100M/1000M) |
|
PoE |
4 ports |
|
Network Function |
HTTP, IPv4, TCP/IP, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, FTP, IP Filter |
|
Max. User Access |
10 users |
|
Storage |
|
Internal HDD |
1 HDD(2.5 inch) |
|
Internal DVD |
2 DVD driver |
|
Auxiliary Interface |
|
USB |
3 ports, USB2.0 |
|
RS232 |
1 port |
|
RS485 |
1 port |
|
General |
|
Power Supply |
DC 19V/4.74A |
|
Power Consumption |
≤40W(With HDD) |
|
Working Environment |
-0 ~+55°C / 10~90%RH / 86~106kpa |
|
Dimension(W×D×H) |
339mm×240mm×47.8mm |
|
Weight |
5.5~6.5 KG(with HDD and DVD driver) |  |
