4MP HD Network Vandal-proof IR Wedge Dome Camera
|
|
| |
Features
>1/3”4Megapixel progressive scan CMOS >Support H.264&MJPEG dual codec >Max 20fps@4M(2688×1520),25/30fps@3M(2304x1296) >Smart Detection supported >WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC, >Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS >3.6mm fixed lens (2.8mm, 6mm optional) >1/1 Alarm in/out, 1/1 audio in/out(only for -AS) >Max. IR LEDs Length 20m >Micro SD memory (only for -AS), IP67, IK10, PoE
Specifications
|
Model |
IPC-HDBW4421F(-AS) |
|
Camera |
|
Image Sensor |
1/3” 4Megapixel progressive scan CMOS |
|
Effective Pixels |
2688(H)x1520(V) |
|
Scanning System |
Progressive |
|
Electronic Shutter Speed |
Auto/Manual, 1/3(4)~1/100000s |
|
Min. Illumination |
0.01lux/F2.0(color),0lux/F2.0 (IR on) |
|
S/N Ratio |
More than 50dB |
|
Video Output |
N/A |
|
Camera Features |
|
Max. IR LEDs Length |
20m |
|
Day/Night |
Auto(ICR)/Color/B/W |
|
Backlight Compensation |
BLC / HLC / WDR(120dB) |
|
White Balance |
Auto/Sunny/Night/Outdoor/Customized |
|
Gain Control |
Auto/Manual |
|
Noise Reduction |
3D |
|
Privacy Masking |
Up to 4 areas |
|
Lens |
|
Focal Length |
3.6mm (2.8mm,6mm optional) |
|
Max Aperture |
F1.8(F2.0,F1.8) |
|
Focus Control |
Manual |
|
Angle of View |
H:84°(106°/56°) |
|
Lens Type |
Fixed lens |
|
Mount Type |
|
|
Video |
|
Compression |
H.264/H.264H/H.264B/MJPEG |
|
Resolution |
4M(2688x1520)/4M(2560x1440)/3M(2304x1296)/1080P(1920 x1080)/1.3M (1280x960)/720P(1280×720)/ D1(704×576/704×480) /CIF(352×288/352×240) |
|
Frame Rate |
Main Stream |
4M(1~20fps)/3M(1~25/30fps) |
|
Sub Stream |
D1/CIF(1 ~ 25/30fps) |
|
Third Stream |
720P(1-20fps) |
|
Bit Rate |
H.264: 32K ~ 10Mbps |
|
Corridor Mode |
Support |
|
Audio |
|
Compression |
N/A |
|
Interface |
N/A |
|
Smart Function(Optional) |
|
Smart detection |
Tripwire |
|
Intrusion |
|
Abandoned/Missing |
|
Scene Change |
|
Audio detect |
|
Face detect |
|
Network |
|
Ethernet |
RJ-45 (10/100Base-T) |
|
Wi-Fi |
N/A |
|
Protocol |
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP,
IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE,
DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x |
|
Compatibility |
ONVIF,PSIA,CGI |
|
Max. User Access |
20 users |
|
Smart Phone |
iPhone, iPad, Android, Windows Phone |
|
Auxiliary Interface |
|
Memory Slot |
Micro SD Max 128GB(only for -AS) |
|
RS485 |
N/A |
|
Alarm |
1/1 channel In/Out(only for -AS) |
|
|
N/A |
|
General |
|
Power Supply |
DC12V, PoE (802.3af) |  |
| |
|
|
|
