> 1/1.7” 12Megapixel progressive scan CMOS
> H.265&H.264 triple-stream encoding
> 20fps@12M(4000×3000),25/30fps@4K(3840×2160)
> DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> Auto back focus(ABF)
> Micro SD memory, PoE
Specifications
|
Camera |
|
Image Sensor |
1/1.7” 12Megapixel progressive scan CMOS |
|
Effective Pixels |
4000(H)x3000(V) |
|
RAM/ROM |
1024MB/128MB |
|
Scanning System |
Progressive |
|
Minimum Illumination |
0.01Lux/F1.2 (Color), 0.001Lux/F1.2 (B/W) |
|
S/N Ratio |
More than 50dB |
|
IR Distance |
N/A |
|
IR On/Off Control |
N/A |
|
IR LEDs |
N/A |
|
Lens |
|
Lens Type |
N/A |
|
Mount Type |
C/CS |
|
Focal Length |
N/A |
|
Max. Aperture |
N/A |
|
Angle of View |
N/A |
|
Optical Zoom |
N/A |
|
Focus Control |
N/A |
|
Close Focus Distance |
N/A |
|
Pan/Tilt/Rotation |
|
Pan/Tilt/Rotation Range |
N/A |
|
Intelligence |
|
IVS (optional) |
Tripwire, Intrusion, Object Abandoned/Missing |
|
Advanced Intelligent Functions |
Face Detection, People Counting, Heat Map |
|
Video |
|
Compression |
H.265/H.264 |
|
Streaming Capability |
3 Streams |
|
Resolution |
12M(4000x3000)/ 4K(3840x2160)/ 6M(3072x2048)/ 5M(2560x1920)/
3M(2048x1536)/ 3M(2304x1296)/ 1080P(1920×1080)/ 1.3M(1280x960)/
720P(1280x720)/ D1(704×576/704x480) / VGA(640x480)/ CIF(352×288/342x240) |
|
Frame Rate |
Main Stream: 12M(1~20fps)/ 4K(1~25/30fps) |
|
Sub Stream: D1 (1 ~ 25/30fps) |
|
Third Stream: 1080P(1~25/30fps) |
|
Bit Rate Control |
CBR/VBR |
|
Bit Rate |
H.264: 24~ 16384Kbps
H.265: 14~ 9984Kbps |
|
Day/Night |
Auto(ICR) / Color / B/W |
|
BLC Mode |
BLC / HLC / DWDR/ SSA |
|
White Balance |
Auto/Natural/Street Lamp/Outdoor/Manual |
|
Gain Control |
Auto/Manual |
|
Noise Reduction |
3D DNR |
|
Motion Detetion |
Off / On (4 Zone, Rectangle) |
|
Region of Interest |
Off / On (4 Zone) |
|
Electronic Image Stabilization (EIS) |
Support |
|
Smart IR |
N/A |
|
Defog |
Support |
|
Digital Zoom |
16x |
|
Flip |
0°/90°/180°/270° |
|
Mirror |
Off / On |
|
Privacy Masking |
Off / On (4 Area, Rectangle) |
|
Audio |
|
Compression |
G.711a/ G.711Mu/ AAC/ G.726 |
|
Network |
|
Ethernet |
RJ-45 (100/1000Base-T) |
|
Protocol |
HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;
DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP;
Bonjour;802.1x;Multicast;ICMP;IGMP;SNMP |
|
Interoperability |
ONVIF, PSIA, CGI |
|
Streaming Method |
Unicast / Multicast |
|
Max. User Access |
10 Users/20 Users |
|
Edge Storage |
NAS
Local PC for instant recording
Mirco SD card 128GB |
|
Web Viewer |
IE, Chrome, Firefox, Safari |
|
Management Software |
Smart PSS, DSS, Easy4ip |
|
Smart Phone |
IOS, Android |
|
Certifications |
|
Certifications |
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B |
|
Interface |
|
Video Interface |
1 port |
|
Audio Interface |
1/1 channel In/Out, 1 Built-in Mic |
|
RS485 |
1 port |
|
Alarm |
2/1 channel In/Out |
|
Electrical |
|
Power Supply |
DC12V, AC24V, PoE(802.3af)(Class 0) |
|
Power Consumption |
<8W |
|
Environmental |
|
Operating Conditions |
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
|
Strorage Conditions |
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
|
Ingress Protection |
N/A |
|
Vandal Resistance |
N/A |
|
Construction |
|
Casing |
Metal |
|
Dimensions |
135.4mm×74.4mm×65.5mm (5.33”×2.93”×2.58”) |
|
Net Weight |
0.66Kg (1.46lb) |
|
Gross Weight |
0.77Kg (1.7lb) | |
