Camera |
|
Image Sensor |
1/1.8" CMOS |
|
Max. Resolution |
2688 (H) × 1520 (V) |
|
ROM |
4 GB |
|
RAM |
1 GB |
|
Scanning System |
Progressive |
|
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
|
Min. Illumination |
0.0007 lux@F1.6 (Color, 30 IRE)
0.0004 lux@F1.6 (B/W, 30 IRE)
0 lux (Illuminator on) |
|
S/N Ratio |
>56 dB |
|
Illumination Distance |
Up to 80 m (262.47 ft) (IR) |
|
Illuminator On/Off Control |
Auto;Manual |
|
Illuminator Number |
4 (IR LED) |
|
Angle Adjustment |
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360° |
|
Lens |
|
Lens Type |
Fixed-focal |
|
Lens Mount |
M12 |
|
Focal Length |
2.8 mm; 3.6 mm; 6 mm |
|
Max. Aperture |
F1.6 |
|
Field of View |
2.8 mm: H: 112°; V: 58°; D: 139°
3.6 mm: H: 88°; V: 50°; D: 102°
6 mm: H: 61°; V: 35°; D: 69° |
|
Iris Control |
Fixed |
|
Close Focus Distance |
2.8 mm: 1.3 m (4.27 ft)
3.6 mm: 1.5 m (4.92 ft)
6 mm: 3.0 m (9.84 ft) |
|
DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
|
|
2.8 mm |
61.5 m (201.77 ft) |
24.6 m
(80.71 ft) |
12.3 m
(40.35 ft) |
6.2 m
(20.34 ft) |
|
|
3.6 mm |
67.6 m (221.78 ft) |
27.0 m
(88.58 ft) |
13.5 m
(44.29 ft) |
6.8 m
(22.31 ft) |
|
|
6 mm |
96.6 m (316.93 ft) |
38.6 m
(126.64 ft) |
19.3 m
(63.32 ft) |
9.7 m
(31.82 ft) |
|
Intelligence |
|
IVS (Perimeter Protection) |
Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection |
|
Smart Object Detection |
Smart abandoned object; smart missing object |
|
SMD 3.0 |
Less false alarm, longer detection distance |
|
AI SSA |
Yes |
|
Face Detection |
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes and 8 expressions; face snapshot set as face, one-inch photo or custom; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting. |
|
People Counting |
Tripwire people counting, generating and exporting report (day/week/month/year); people counting in area and queue management, generating and exporting report (day/week/month); 4 rules can be set for tripwire, people counting in area and queue management. |
|
Heat Map |
Yes |
|
Video Metadata |
"Motor vehicle, non-motor vehicle, face, human body detection; track; snapshot; snapshot optimization; optimal face snapshot upload.
Motor vehicle attributes: vehicle type, vehicle color, vehicle logo and other attributes : seatbelt, smoking, calling.
Non-motor vehicle attributes: type, color, number of people, top type and color, hat.
Human body attributes: gender, top/bottom type and color, bag, hat and umbrella.
Face attributes: gender, age, expressions, glasses, face mask and beard. " |
|
Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
|
Video |
|
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
|
Smart Codec |
Smart H.265+; Smart H.264+ |
|
AI Coding |
AI H.265; AI H.264 |
|
Video Frame Rate |
Main stream: 2688 × 1520 (1 fps–25/30 fps) /1920 × 1080 (1 fps–50/60 fps)
Sub stream: D1@(1–25/30 fps)
Third stream: 1080p@(1–25/30 fps)
Fourth stream: 720p@(1–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
|
Stream Capability |
4 streams |
|
Resolution |
4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048 × 1535); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
|
Bit Rate Control |
CBR/VBR |
|
Video Bit Rate |
H.264: 32 kbps–16384 kbps
H.265: 12 kbps–11008 kbps |
|
Day/Night |
Auto(ICR)/Color/B/W |
|
BLC |
Yes |
|
HLC |
Yes |
|
WDR |
140 dB |
|
Scene Self-adaptation (SSA) |
Yes |
|
White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
|
Gain Control |
Auto |
|
Noise Reduction |
3D NR |
|
Motion Detection |
OFF/ON (4 areas, rectangular) |
|
Region of Interest (RoI) |
Yes (4 areas) |
|
Smart Illumination |
Yes |
|
Defog |
Yes |
|
Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 4M (2688 × 1520) resolution and lower) |
|
Mirror |
Yes |
|
Privacy Masking |
8 areas |
|
Audio |
|
Built-in MIC |
Yes |
|
Audio Compression |
G.711a; G.711Mu; PCM; G.726; G.723 |
|
Alarm |
|
Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; external alarm; face detection; SMD; people counting in area; stay detection; people counting; people number error detection; queue people number alarm; queue time alarm; security exception |
|
Network |
|
Network Port |
RJ-45 (10/100 Enhancement Base-T) |
|
SDK and API |
Yes |
|
Network Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P |
|
Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; |
|
User/Host |
20 (Total bandwidth: 80 M) |
|
Storage |
FTP; SFTP; Micro SD card (support max. 512 GB); NAS |
|
Browser |
IE: IE 9 and later
Chrome: Chrome 102 and later
Firefox: Firefox 88 and later |
|
Management Software |
SmartPSS Lite; DSS; DMSS |
|
Mobile Client |
iOS; Android |
|
Cyber Security |
Configuration encryption;Trusted execution;Digest;Security logs;WSSE;Account lockout;syslog;Video encryption;802.1x;IP/MAC filtering;HTTPS;Trusted upgrade;Trusted boot;Firmware encryption;Generation and importing of X.509 certification |
|
Certification |
|
Certifications |
CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
|
Power |
|
Power Supply |
12 VDC/PoE (802.3af)/ePoE |
|
Power Consumption |
Basic: 4.1 W (12 VDC); 5.2 W (PoE)
Max. (H.265+ WDR+ Intelligence on+IR on): 8.3 W (12 VDC); 9.8 W (PoE) |
|
Environment |
|
Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
|
Operating Humidity |
≤95% |
|
Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
|
Storage Humidity |
10%–95% (RH), non-condensing |
|
Protection |
IP67; IK10 |
|
Structure |
|
Casing Material |
Metal |
|
Product Dimensions |
244.1 mm × 79.0 mm × 75.9 mm (9.61" × 3.11" × 2.99") (L × W × H) |
|
Net Weight |
0.82 kg (1.81 lb) |
|
Gross Weight |
1.08 kg (2.38 lb) |
