Camera |
|
Image Sensor |
Panoramic network camera: 1/1.8"CMOS PTZ camera:1/1.8"CMOS |
|
Max. Resolution |
Panoramic network camera:8192 × 1800
PTZ camera: 2560 × 1440 |
|
ROM |
Panoramic network camera:4 GB
PTZ camera:4 GB |
|
RAM |
Panoramic network camera:4 GB
PTZ camera:1 GB |
|
Scanning System |
Progressive |
|
Electronic Shutter Speed |
Panoramic network camera:Auto/Manual 1/3 s-1/100,000 s
PTZ Camera:Auto/Manual 1/1 s-1/300,000 s |
|
Min. Illumination |
Panoramic network camera:0.001 lux @F1.0(Color, 30 IRE); 0.0001 lux@F1.0(B/W, 30 IRE)
PTZ camera:0.001 lux @F1.6(Color, 30 IRE); 0.0001 lux @F1.6(B/W, 30 IRE); 0 lux (Illuminator on) |
|
S/N Ratio |
Panoramic network camera:51 dB
PTZ camera:51.5 dB |
|
Illumination Distance |
Panoramic network camera:NA
PTZ camera:≥100 m (328.08 ft) (IR on) |
|
Illuminator On/Off Control |
Auto; Zoomprio; Manual |
|
Illuminator Number |
Panoramic network camera:NA
PTZ camera:4(IR LED) |
|
Lens |
|
Lens Type |
Panoramic network camera: Fixed-focal
PTZ camera: Motorized vari-focal |
|
Lens Mount |
Panoramic network camera: M16
PTZ camera: Module |
|
Focal Length |
Panoramic network camera 2.8 mm
PTZ camera: 5.3 mm–134 mm, optical zoom (25times) |
|
Max. Aperture |
Panoramic network camera: F1.0
PTZ camera: F1.6–F4.0 |
|
Field of View |
Panoramic network camera: H: 360°; V: 103°;
PTZ camera:H: 3.5°–58°; V: 2°–35°; D: 2°–64° |
|
Iris Control |
Panoramic network camera: Fixed PTZ camera: Auto |
|
Close Focus Distance |
Panoramic network camera:1.4 m (4.59 ft)
PTZ camera:0.5 m–7 m (1.64 ft–22.96 ft) |
|
DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
|
|
Panoramic network camera |
57.9 m (189.96 ft) |
23.2 m
(76.11 ft) |
11.6 m
(38.05 ft) |
5.8 m (19.02 ft) |
|
|
PTZ camera |
1688 m (5538.05 ft) |
675 m (2214.56 ft) |
337 m (1105.64 ft) |
168 m (551.18 ft) |
|
Intelligence |
|
IVS (Perimeter Protection) |
Panoramic network camera: Intrusion, tripwire
PTZ camera:Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); parking detection, loitering detection, and people gathering. |
|
Face Detection |
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting. |
|
Video Metadata |
Motor vehicle, non-motor vehicle, face, human body detection; track; snapshot; snapshot optimization; optimal face snapshot upload.
Motor vehicle attributes: license plate, vehicle type, vehicle color, vehicle logo and other attributes : seatbelt, smoking, calling.
Non-motor vehicle attributes: type, color, number of people, top type and color, helmet.
Human body attributes: gender, top/bottom type and color, bag, hat and umbrella.
Face attributes: gender, age, expressions, glasses, face mask and beard. |
|
Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
|
Video |
|
Video Compression |
H.265; H.264; H.264H; MJPEG (Only supported by the sub stream) |
|
Smart Codec |
Smart H.265+; Smart H.264+ |
|
Video Frame Rate |
Panoramic network camera:
Main stream: 8192 × 1800@(1-25/30fps)
Sub stream: 2048 × 452@(1-25/30fps)
Third stream: 3840 × 832@(1-25/30fps)
PTZ camera:
Main stream: 2688 × 1520@(1-25/30fps)
Sub stream: 704 × 480@(1-25/30fps)
Third stream: 1920 × 1080@(1-25/30fps) |
|
Stream Capability |
3 streams |
|
Resolution |
Panoramic network camera:
Main stream: 8192 × 1800; 7680 × 1680; 5760 × 1264; 4096 × 900
Sub Stream: 2048 × 452
Third Stream: 3840 × 832; 2560 × 560
PTZ camera:
Main stream: 2560 × 1440; 1920 × 1080; 1280 × 960; 1280 × 720
Sub Stream: 704 × 576; 352 × 288
Third Stream: 1920 × 1080; 1280 × 960; 1280 × 720 |
|
Bit Rate Control |
CBR/VBR |
|
Video Bit Rate |
Panoramic network camera:
H.264: 3584 Kbps –18176 Kbps
H.265: 1280 Kbps –11008 Kbps
PTZ camera:
H.264: 2816 Kbps – 13056 Kbps
H.265: 1024 Kbps – 7936 Kbps |
|
Day/Night |
Auto (ICR)/Color/B/W |
|
BLC |
Yes |
|
HLC |
Yes |
|
WDR |
Panoramic network camera: DWDR
PTZ camera: WDR (120 dB ) |
|
White Balance |
Panoramic network camera: Auto/Natural/street lamp/outdoor/manual/regional Custom
PTZ camera: Auto/indoor/outdoor/tracking/manual/sodium lamp/natural/street lamp |
|
Gain Control |
Auto; Manual |
|
Noise Reduction |
3D NR |
|
Motion Detection |
OFF/ON (4 areas, rectangular) |
|
Region of Interest (RoI) |
Yes (4 areas) |
|
Image Stabilization |
Panoramic network camera: NA
PTZ camera: Electronic Image Stabilization (EIS) |
|
Smart Illumination |
Panoramic network camera:NA
PTZ camera:Yes |
|
Defog |
Panoramic network camera: NA
PTZ camera: Yes |
|
Image Rotation |
0°/180° (PTZ camera) |
|
Privacy Masking |
Panoramic network camera: 4 areas
PTZ camera: 8 areas |
|
Audio |
|
Built-in MIC |
Yes |
|
Built-in Speaker |
Yes |
|
Audio Compression |
PCM; G.711A; G.711Mu; G.726; G.723 |
|
Alarm |
|
Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; parking detection; scene changing; audio detection; voltage detection; external alarm; video metadata; safety exception; |
|
Network |
|
Network Port |
RJ-45(10/100/1000 Base-T) |
|
SDK and API |
Yes |
|
Network Protocol |
IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
|
Cyber Security |
Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade |
|
Interoperability |
ONVIF (Profile S/Profile G); CGI; Milestone |
|
User/Host |
9 (Total bandwidth: 176 M) |
|
Storage |
Micro SD card (support max. 512GB); FTP; SFTP; NFS; SMB |
|
Browser |
IE: IE11;
Chrome;
Firefox |
|
Management Software |
DSS |
|
Certification |
|
Certifications |
CE-LVD:EN62368-1
CE-EMC:Electromagnetic Compatibility Directive 2014/30/EU
FCC:47 CFR FCC Part 15, Subpart B
UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
|
PTZ Dome |
|
Pan/Tilt Range |
Pan: 0° to 360° endless
Tilt: –10° to 90°, auto flip 180° |
|
Manual Control Speed |
Pan: 0.1°/s–120°/s
Tilt: 0.1°/s–50°/s |
|
Positioning Accuracy |
Pan: 0.1°
Tilt: 0.1° |
|
Remote PTZ Reset |
Yes |
|
Preset |
300 |
|
Tour |
8 (up to 32 presets per tour) |
|
Pattern |
5 |
|
Scan |
5 |
|
Power-off Memory |
Yes |
|
Idle Motion |
Preset/Pattern/Tour/Scan |
|
Time Task |
Yes |
|
Three-dimensional Positioning |
Yes |
|
PTZ Limit |
Yes |
|
Position Display |
Yes |
|
Information Display |
Yes |
|
Time Display |
Yes |
|
Port |
|
Audio Input |
2 channels (terminal) |
|
Audio Output |
1 channel (terminal) |
|
Alarm Input |
3 channels in: 5 mA 3V–5 VDC |
|
Alarm Output |
2 channels out: 1,000 mA 30 VDC/500 mA 50 VAC |
|
Analog Output |
1 channel (CVBS output: BNC) |
|
Power |
|
Power Supply |
DC 36V |
|
Power Consumption |
Basic: 35 W (36 VDC)
Max. (Basic power consumption + WDR + intelligence on + IR on + PTZ operation ): 45 W (36 VDC) |
|
Environment |
|
Operating Temperature |
–40 °C – +60 °C (–104 °F to +140 °F) |
|
Operating Humidity |
≤95% |
|
Storage Temperature |
–40 °C – +70 °C (–104 °F to +158 °F) |
|
Protection |
IP67 |
|
Structure |
|
Casing Material |
Metal + plastic |
|
Product Dimensions |
326 mm × Φ280 mm (12.83" × Φ11.02") |
|
Packaging Dimensions |
394 mm × 352 mm × 468 mm (15.51" × 13.86" × 18.43") |
|
Net Weight |
7 kg (15.43 lb) |
|
Gross Weight |
10.4 kg (22.93 lb) |
