Video Balun with Power of 17V DC, Measuring 200 x 70 x 38mm...
|
|
| |
Key Specifications/Special Features:
- 4 Channels active video/audio/power receiver
- This device is capable of receiving video, audio and power DC 12V over UTP cable
- Technical informations:
- Video frequency response: 6Mhz DC common-mode/differential-mode
- Rejection: 15kHz/6MHz/60dB
- Audio/data: yes
- Audio: 14dB
- Power: 17V DC
- Impedance Coax, male BNC: 75ΩUTP(screwless) terminal block or UTP RJ45
- Data connector: 100Ω
- Wire type one unshielded twisted pair: 24 to 16AWG (0.5 to 1.31mm)
- Per video signal: DC loop resistance 52 Ohms per 1,000 ft (18 Ohms per 100m)
- Surge suppression: 6,000V/1.2μ/S x 5μ S
- Controls brightness/range
- UTP port RJ45 and terminal block
- Dimensions: 200 x 70 x 38mm
- Weight: 390g
- Environment temperature: -10 to 50 degrees C
- Humidity: 0 to 95%
|
| |
|
|
|
|
