The model ST-VPAD104-AC is a transceiver hub that allows transmit CCTV video、audio、data and DC

power over single network cable at the same time.The device uses single Cat5/5e/6 SECTEC cable as

 transmission medium and work together with ST-VPAD-RM,it can realtime transmit 4-ch PAL,NTSC,

SECAM color or monochrome video signals、4-ch mono 101monitor audio、4-ch RS485 or RS232 signals up to 300m,

and provide 12V DC power to each camera,simplified the project wiring. In practical project,it need to used in pair,

it is featured with long transmission distance,high performance transmission,super anti-interference and etc.,

professional application in video security monitoring project...



· Power supply: Using 100W（36V/2.8A）high power DC power;
·Main function: Transmit 4-CH  video 、mono audio 、data and 12V DC power over single Cat5/5e/6 SECTEC cable;
·Transmission distance: 0～300M(12V DC output);
·Safety performance: Anti-interference 、super surge  protection 、anti-static protection、transient shock  protection;
·Appearance design:High hardness antirust iron shell, sophisticated technology, solid and durable ,RJ45、

BNC connector convenience and good in sight;
