4ch active video receiver, transmission of PAL/NTSC Real-time video, audio transmission optional...
|
|
| |
■ Product Introduction
4-Channel Active Video Receiver;
Long Distance Transmission of PAL/NTSC Real-time Video&audio;
Exceptional Interference Rejection;
Adjustment State Indication;
Built-in Surge Protection, Lighting Protection and Other Protection Setting;
Convenient Wiring, Higher Cable Utilization Rate and Lower Composite Wiring Cost;
Simple User Operation.
■ Technique Parameter
|
Model |
ST-410R/A |
|
Spec |
4CH Active Video/date/Power Power-Video-Data (PVD) Transceiver |
|
Video |
Frequency respons:DC-6Mhz Conmmon-mode/Differential-mode Rejection:15Khz 6Mhz 60dB typ |
|
Audio/data |
YES（Audeo 14dB） |
|
Power |
DC 12V |
|
Impedance |
Coax,male BNC:75ΩUTP(Screwless)Terminal Block or UTP RJ45 Data Connector:100Ω |
|
Wire type |
One Unshielded Twisted Pair 24-16AWG(0.5-1.31mm) Per video signal:DC Loop Resistance 52 ohms per 1,000 ft(18 ohms per 100m) |
|
Surge suppression |
6000V 1.2μ S*5μ S |
|
Control |
Brightness/Range |
|
UTP Port |
RJ45 AND Terminal Block |
|
Dimensions(mm) |
200*70*38 |
|
Weigth(g) |
390 |
|
Environment |
Temperature:-10~+50℃ Humidity:0~95% | |
| |
|
|
|
|
