Use of efficient, environmental protection switching power supply circuit frame
Optimization of the shape and structure to facilitate the construction systems
Small ripple & noise -- video output signal more stable, clearly images
Splitter output -- by-pass failure to protect other equipment to work
Power protection -- Output over-voltage protection, over-current protection, short circuit protection
Input: 190-240V AC @ 50-60Hz
Output voltage: 13.8V ±2% DC
Output Current: 3Amp
Output Channel: 6 Channel
Over-current Protection: 3.6A±5%
Ripple & Noise: ≤100mV
Efficiency ≥85%
Charge Voltage: 13.5V
Charge Current (Max.): 1Amp
Battery Under-voltage Protection: 10V
Enclosure Dimensions: 203*163*74mm
Weight: 1.2kg |
