PRODUCT FEATURE
Accurate constant driver circuit develops excellent performance of LED;
Dot matrix super power LED brings high efficacy, low light decay and long service life;
More energy saving by power factor correction, PF: 0.9-0.98;
IP66 waterproof and -40℃ to +55℃ working temperature;
0-90 degrees angle extending range;
TECHNICAL SPECIFICATION
LED type: 36pcs 2W dot-matrix IR LED
Wavelength: 740nm/850nm/940nm
Beam Angle: 15°-230°
Beam Distance: 240m-40m
Bracket: Wall mount bracket
Working Voltage: AC85-265V/DC12-24V/AC24V
Power Consumption: 66W
Day/Night Switch: Auto
Working Temperature: -40℃ to +55℃
Protection Level: IP66
Color: Black
Panel: Tempered glass panel
Housing: Aluminum Die Casting Housing
N.W/G.W: 3.9KG/4.5KG
Dimension: 378*135*91mm
Warranty: 3-5years
Model Beam Angle Viewing distance （850nm）
ST-H123-15-A-IR 15° - 45° 240m-140m
ST-H123-30-A-IR 30° - 90° 160m-100m
ST-H123-45-A-IR 45° - 150° 110m-65m
ST-H123-60-A-IR 60° - 180° 80m-50m
ST-H123-90-A-IR 90° - 200° 60m-40m
ST-H123-120-A-IR 120° - 230° 40m-30m
Viewing distance is tested by SONY 1/3" CCD Camera.
To achieve the distance needed, please pay attention to your camera specification
and lens before purchase. It is normal phenomenon that distance may vary due to different cameras and lens. |
