PRODUCT FEATURE
Accurate constant driver circuit develops excellent performance of LED;
Dot matrix super power LED brings high efficacy, low light decay and long service life;
More energy saving by power factor correction, PF: 0.9-0.98;
IP66 waterproof and -40℃ to +55℃ working temperature;
TECHNICAL SPECIFICATION
LED type: 16pcs 2W dot-matrix IR LED
Wavelength: 740nm/850nm/940nm
Beam Angle: 15°-120°
Beam Distance: 150m-30m
Bracket: Wall mount bracket
Working Voltage: AC85-265V/DC12-24V/AC24V
Power Consumption: 28W
Day/Night Switch: Auto
Working Temperature: -40℃ to +55℃
Protection Level: IP66
Color: Black
Panel: Tempered glass panel
Housing: Aluminum Die Casting Housing
N.W/G.W: 1.6KG/2KG
Dimension: 170*213*124mm
Warranty: 3-5years
Model Beam Angle Viewing distance (850nm)
ST-H161-15-A-IR 15° 150m
ST-H161-30-A-IR 30° 100m
ST-H161-45-A-IR 45° 70m
ST-H161-60-A-IR 60° 50m
ST-H161-90-A-IR 90° 40m
ST-H161-120-A-IR 120° 30m
Viewing distance is tested by SONY 1/3" CCD Camera.
To achieve the distance needed, please pay attention to your camera specification
and lens before purchase. It is normal phenomenon that distance may vary due to different cameras and lens. |
