PRODUCT FEATURE
Accurate constant driver circuit develops excellent performance of LED;
Dot matrix super power LED brings high efficacy, low light decay and long service life;
More energy saving by power factor correction, PF: 0.9-0.98;
IP66 waterproof and -40℃ to +55℃ working temperature;
TECHNICAL SPECIFICATION
LED type: 4pcs 2W dot-matrix IR LED
Wavelength: 740nm/850nm/940nm
Beam Angle: 15°-90°
Beam Distance: 120m-45m
Bracket: Wall mount bracket
Working Voltage: AC85-265V/DC12-24V/AC24V
Power Consumption: 10W
Day/Night Switch: Auto
Working Temperature: -40℃ to +55℃
Protection Level: IP66
Color: Beige
Panel: Tempered glass panel
Housing: Aluminum Die Casting Housing
N.W/G.W: 0.45KG/0.6KG
Dimension: 84*84*80mm
Packing Dimension: 180*155*120mm
Warranty: 2years
Model Beam Angle Viewing distance(850nm)
ST-04D-15-IR 15° 120m
ST-04D-30-IR 30° 100m
ST-04D-45-IR 45° 80m
ST-04D-60-IR 60° 60m
ST-04D-90-IR 90° 45m
Viewing distance is tested by Watec/WAT-902H 1/3" CCD Camera.
To achieve the distance needed, please pay attention to your camera specification
and lens before purchase. It is normal phenomenon that distance may vary due to different cameras and lens. |
