Features
> Full HD standalone network video decoder for TV wall monitoring system
> Support multiple devices: Network camera, DVR, NVS
> H.264/MPEG-4 dual codec video decoding
> Support multiple resolution decoding: QCIF/CIF/2CIF/ HD1/D1/720P/1080P
> Up to 1080P display output & various interface: HDMI, VGA and BNC
> Support various split-window modes
> Alarm input/output, RS232, RS485
> Powerful 1000M Ethernet interface
> WEB GUI interface for easy setup and control
> Standard 19-inch 1U chassis for easy installation
Technical Specifications
|
Model |
NVS0104DH |
NVS0404DH |
|
System |
|
Main Processor |
Dual-core embedded processor |
|
Operating System |
Embedded LINUX |
|
Video |
|
Video Output |
HDMI x 1, VGAI x 1, BNC x 1 |
HDMI x 4, VGAI x 4, BNC x 4 |
|
Video Standard |
H.264 / MPEG4 |
|
Video Decoding |
D1: 16 channel, 2MBps
720P: 8 channel, 4MBps
1080P: 4 channel, 8MBps |
D1: 28 channel, 2MBps
720P: 14 channel, 4MBps
1080P: 7 channel, 8MBps |
|
Video Frame Rate |
PAL: 1~25fps, NTSC: 1~30fps |
|
Audio |
|
Audio Output |
HDMI x 1, BNC(200~3000mV, 5KΩ) x 1 |
HDMI x 4, BNC(200~3000mV, 5KΩ) x 4 |
|
Audio Standard |
PCM / G711 |
|
Voice Intercom |
1 channel input, BNC(200-2800mV, 30KΩ), 1 channel output, BNC(200-3000mV, 5KΩ) |
|
Display |
|
Display Split |
1/4/9/16 |
Display 1: 1/4/9/16
Display 2~4: 1/4 |
|
Display Resolution |
1280 x 1024,1280 x 720,1920 x 1080 |
|
Tour Display |
Support, 1/4/9 display split |
|
Network |
|
Ethernet |
RJ-45 port (10/100M/1000M) |
|
Network Protocol |
HTTP, TCP/IP, UDP, NTP, DHCP, DNS |
|
Remote Operation |
System setting , Playback, Upgrade, Log information |
|
Alarm |
|
Alarm Input |
16 channel |
|
Alarm Output |
8 channel relay output (30VDC/1A, 125VAC 0/5A activation output) |
|
Trigger Events |
Tour, Alarm |
|
Auxiliary Interface |
|
USB Interface |
USB2.0 port |
|
RS232 |
Keyboard, PC communication |
|
RS485 |
2 duplex RS485 ports |
|
Working Environment |
|
Power Supply |
DC12V,3.3A |
DC12V, 5.0A |
|
Power Consumption |
Max 10W |
Max 40W |
|
Working Environment |
0 ~+55°C / 10~90%RH / 86~106kpa |
|
Dimension |
1U, 440mm x 300mm x 42mm(W×D×H) |
|
Weight |
3.00KG |
3.50 KG |  |
