Overview
• 192ch@D1,96ch@ 720P,48ch@1080P
• 16 HDDs supported(each one up to 3TB)
• Raid0,Raid1,Raid5,Raid6,JBOD,Single
• iSCSI, SAMBA, NFS, FTP
• HDD expansion: four expansion device
• 2 expansion Mini SAS
• 4 RJ-45 10/100/1000Mbp
Features
> IPSAN/NASintegrated solution
> internal cable-free design
> Easy data storage and file sharing thanks to High-performance and scalability
> Data’s safe thanks to fault-tolerant protection mechanisms
> Support RAID0,RAID1,RAID5, hot-swappable
> 24/7 non-stop storage capability thanks to qualified redundant fans and power supply
> Support industrial protocols such as SAMBA,NFS,ISCSI,CIFS,FTP,HTTP and etc.
> Support Windows,Linux,Unix and other OS.
> Easy operation(only takes max. 10 minutes to finish set-up) thanks to the web-based configuration management
> Compatible to multiple software platforms
Technical Specifications
|
Model |
ESS3116X |
|
System |
|
|
Main Processor |
Intel SandyBridgequad-core processor |
|
Operating System |
Embedded LINUX |
|
Power Supply |
Single Power Supply(-ES) |
|
Fan |
Redundant two-ball bearing fans,
MTBF>100,000 hours,
Support online replacement |
|
Motherboard |
Server class(24/7 operation) |
|
Memory |
4G |
|
Chassis |
Hot-dip galvanized steel sheet (1.2mm thickened)
High-precise aluminum alloy slide
Self-patent drawer-type HDD rack |
|
User Interface |
WEB GUI |
|
Performance |
|
Storage Protocol |
iSCSI, SAMBA, NFS, FTP |
|
Video Input |
192ch@D1,96ch@ 720P,48ch@1080P |
|
HDD Management |
|
Hard Disk |
16 SATAⅡports,16 HDDs supported(each one up to 3TB) |
|
Raid Mode |
Raid0,Raid1,Raid5,Raid6,JBOD,Single |
|
Expansion Mini SAS |
2 Mini SAS |
|
HDD Hot Standby |
Support global HDD Hot Standby |
|
HDD Expansion |
Support up to four expansion device, |
|
Network |
|
Interface |
4 RJ-45 10/100/1000Mbps |
|
Network Port Feature |
MultipleEthernet-port load balance bindingor
4-1000Mbps Ethernet ports |
|
Environmental |
|
Power Supply |
100V-240V AC, 47-63Hz |
|
Power Consumption |
<400W(include HDD),<200W(exclude HDD) |
|
Working Temperature |
0℃~40℃ |
|
Working Humidity |
10%~80% (Non-condensation) |
|
Storage Temperature |
-20℃~70℃ |
|
Storage Humidity |
5%~90% (Non-condensation) |
|
Working Elevation |
-60m~3000m |
|
Dimension(WxDxH) |
448mm x 490.4mm x 133.2mm |
|
Weight |
23Kg |
|
Mounting |
19 feet standard rack-mounted | |
