Features
>Support HDCVI/Analog/IP Video input
>Up to 4/8 cameras with 1080p realtime preview
>H.264 dual-stream video compression
>HCVR7204/7208A-V2: All channel 1080P realtime recording
>4/8 channel synchronous realtime playback, GRID interface & smart search
>HDMI/VGA simultaneous video output
>Support 2 SATA HDDs up to 8TB, 2 USB2.0
>3D intelligent positioning with Dahua PTZ dome camera
>ONVIF Version 2.3 conformance
>Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon,
CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech , and etc.
>Multiple network monitoring: Web viewer, CMS(DSS/Smart PSS)&Smart Phone(DMSS)
Specifications
|
Model |
HCVR7204A-V2 |
HCVR7208A-V2 |
|
System |
|
Main Processor |
Embedded processor |
|
Operating System |
Embedded LINUX |
|
Video |
|
Input |
4 channel, BNC |
8 channel, BNC |
|
Standard |
HDCVI |
1080P/720P HDCVI Camera |
|
Analog |
NTSC(525Line, 60f/s), PAL(625Line, 50f/s) |
|
IP |
1080P/720P/D1/CIF IP Camera |
|
Audio |
|
Input |
4 channel, RCA |
|
Output |
1 channel, RCA |
|
Two-way Talk |
Reuse audio input/output channel 1 |
|
Display |
|
Interface |
1 HDMI, 1 VGA |
|
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768, 800×600 |
|
Display Split |
1/4 |
1/4/8/9 |
|
Privacy Masking |
4 rectangular zones (each camera) |
|
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
|
Recording |
|
Video/Audio Compression |
H.264/G.711 |
|
Resolution |
1080P(1920×1080)/720P(1280×720)/960H(960×576/960×480)/D1/4CIF
(704×576/704×480)/CIF(352×288/352×240)/QCIF(176×144/176×120) |
|
Record Rate |
Main Stream: |
1080P/720P/960H/D1/HD1/2CIF/CIF(1~25/30fps) |
|
Extra Stream |
CIF/QCIF(1~25/30fps),D1(1~12/15fps) |
|
Bit Rate |
48~6144Kb/s |
|
Record Mode |
Manual, Schedule(Regular(Continuous), MD), Stop |
|
Record Interval |
1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
|
Video Detection & Alarm |
|
Trigger Events |
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Spot, Snapshot, Buzzer & Screen tips |
|
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
|
Alarm Input |
4 channel |
16 channel |
|
Relay Output |
3 channel |
|
Playback & Backup |
|
Sync Playback |
1/4 |
1/4/9 |
|
Search Mode |
Time/Date, MD & Exact search (accurate to second) |
|
Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file,
Previous file, Next camera, Previous camera, Full screen,
Repeat, Shuffle, Backup selection, Digital zoom |
|
Backup Mode |
USB Device/Inernal SATA burner/Network |
|
Network |
|
Ethernet |
RJ-45 port (10/100M/1000M) |
|
Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP,
DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P |
|
Max. User Access |
128 users |
|
Smart Phone |
iPhone, iPad, Android, Windows Phone |
|
Storage |
|
Internal HDD |
2 SATA ports, up to 8TB |
|
Auxiliary Interface |
|
USB Interface |
2 ports (1 Rear), USB2.0 |
|
RS485 |
1 port, For PTZ control |
|
General |
|
Power Supply |
DC12V/5A |
|
Power Consumption |
15W(without HDD) |
|
Working Environment |
-10°C ~+55°C / 10%~90%RH / 86~106kpa |
|
Dimension(W×D×H) |
1U, 375mm×285mm×55mm |
|
Weight |
2.35KG(without HDD) |
|
