Features
>Support HDCVI/Analog/IP Video input
>Up to 4/8/16 cameras with 1080p realtime preview
>H.264 dual-stream video compression
>HCVR5404/5408/5416L-V2: All channel 720P realtime or 1080P non-realtime recording
>4/8/16 channel synchronous realtime playback, GRID interface & smart search
>HDMI/VGA/TV simultaneous video output
>Support 4 SATA HDDs up to 16TB, 1 eSATA up to 16TB,3 USB2.0
>3D intelligent positioning with Dahua PTZ dome camera
>ONVIF Version 2.3 conformance
>Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus,
Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotech , and etc.
>Multiple network monitoring: Web viewer, CMS(DSS/Smart PSS)&Smart Phone(DMSS)
Specifications
|
Model |
HCVR5404L-V2 |
HCVR5408L-V2 |
HCVR5416L-V2 |
|
System |
|
Main Processor |
Embedded processor |
|
Operating System |
Embedded LINUX |
|
Video |
|
Input |
4 channel, BNC |
8 channel, BNC |
16 channel, BNC |
|
Standard |
HDCVI |
1080P/720P HDCVI Camera |
|
Analog |
NTSC(525Line, 60f/s), PAL(625Line, 50f/s) |
|
IP |
1080P/720P/D1/CIF IP Camera |
|
Audio |
|
Input |
4 channel, BNC |
|
Output |
1 channel, BNC |
|
Two-way Talk |
1 channel Input, 1 channel Output, BNC |
|
Display |
|
Interface |
1 HDMI, 1 VGA, 1 TV |
|
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768, 800×600 |
|
Display Split |
1/4 |
1/4/8/9 |
1/4/8/9/16 |
|
Privacy Masking |
4 rectangular zones (each camera) |
|
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
|
Recording |
|
Video/Audio Compression |
H.264/G.711 |
|
Resolution |
1080P(1920×1080)/720P(1280×720)/960H(960×576/960×480)/D1/
4CIF(704×576/704×480) / CIF(352×288/352×240) / QCIF(176×144/176×120) |
|
Record Rate |
Main Stream: |
1080P(1~12/15fps)/720P/960H/D1/HD1/2CIF/CIF(1~25/30fps) |
|
Extra Stream |
CIF/QCIF(1~25/30fps) |
|
Bit Rate |
48~4096Kb/s |
|
Record Mode |
Manual, Schedule(Regular(Continuous), MD), Stop |
|
Record Interval |
1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
|
Video Detection & Alarm |
|
Trigger Events |
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Spot,
Snapshot, Buzzer & Screen tips |
|
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
|
Alarm Input |
4 channel |
8 channel |
16 channel |
|
Relay Output |
6 channel |
|
Playback & Backup |
|
Sync Playback |
1/4 |
1/4/9 |
1/4/9/16 |
|
Search Mode |
Time/Date, MD & Exact search (accurate to second) |
|
Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file,
Previous file, Next camera, Previous camera, Full screen, Repeat,
Shuffle, Backup selection, Digital zoom |
|
Backup Mode |
USB Device/eSATA Device/Internal SATA burner/Network |
|
Network |
|
Ethernet |
RJ-45 port (10/100M/1000M) |
|
Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS,
PPPOE, DDNS, FTP, IP Filter, SNMP, P2P |
|
Max. User Access |
128 users |
|
Smart Phone |
iPhone, iPad, Android, Windows Phone |
|
Storage |
|
Internal HDD |
4 SATA ports(4 HDDs or 3HDDs+1 CD/DVD-RW), up to 16TB |
|
External HDD |
1 eSATA port (Max 4 SATA HDDs), up to 16TB |
|
Auxiliary Interface |
|
USB Interface |
3 ports (2 Rear), USB2.0 |
|
RS232 |
1 port, For PC communication & Keyboard |
|
RS485 |
1 port RS485 for PTZ control,1 port RS422 for Keyboard |
|
General |
|
Power Supply |
AC 100~240 V, 50/60 Hz |
|
Power Consumption |
40W(Without HDD) |
|
Working Environment |
-10°C ~+55°C / 10%~90%RH / 86~106kpa |
|
Dimension(W×D×H) |
1.5U, 440mm×416mm×68mm |
|
Weight |
6KG(without HDD) |
|
