Features
>Up to 4 cameras with 1080p realtime preview >H.264 dual-stream video compression >HCVR7104C-V2: All channel 1080P realtime recording >HDMI/VGA simultaneous video output >All channel synchronous realtime playback, GRID interface & smart search >3D intelligent positioning with Dahua PTZ dome camera >Support 1 SATA HDD up to 4TB, 2 USB2.0 >Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Specifications
Model |
HCVR7104C-V2 |
System |
Main Processor |
Embedded processor |
Operating System |
Embedded LINUX |
Video |
Input |
4 channel, BNC |
Standard |
NTSC(525Line, 60f/s), PAL(625Line, 50f/s) |
Display |
Interface |
1 HDMI, 1 VGA |
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768, 800×600 |
Display Split |
1/4 |
Privacy Masking |
4 rectangular zones (each camera) |
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Recording |
Video/Audio Compression |
H.264/G.711 |
Resolution |
1080P(1920×1080)/720P(1280×720)/960H(960×576/960×480)/D1/4CIF(704×576/704×480) / CIF(352×288/352×240) / QCIF(176×144/176×120) |
Record Rate |
Main Stream: |
1080P/720P/960H/D1/HD1/2CIF/CIF(1~25/30fps) |
Extra Stream |
CIF/QCIF(1~25/30fps), D1(1~12/15fps) |
Bit Rate |
48~6144Kb/s |
Record Mode |
Manual, Schedule(Regular(Continuous), MD), Stop |
Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Video Detection |
Trigger Events |
Recording, PTZ, Tour, Video Push, Email, FTP, Spot, Buzzer & Screen tips |
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
Playback & Backup |
Sync Playback |
1/4 |
Search Mode |
Time/Date, MD & Exact search (accurate to second) |
Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
Backup Mode |
USB Device/Internal SATA burner/Network |
Network |
Ethernet |
RJ-45 port (10/100M) |
Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P |
Max. User Access |
128 users |
Smart Phone |
iPhone, iPad, Android, Windows Phone |
Storage |
Internal HDD |
1 SATA port, up to 4TB |
Auxiliary Interface |
USB Interface |
2 ports(2 Rear), USB2.0 |
General |
Power Supply |
DC12V/2A |
Power Consumption |
10W(without HDD) |
Working Environment |
-10°C ~+55°C / 10%~90%RH / 86~106kpa |
Dimension(W×D×H) |
205mm×205mm×40mm |
Weight |
0.5KG(without HDD) | |
