Overview
>8/16/32/64ch IP camera inputs
>1/1ch Mic in/out
>8/16/32/64ch@1080p
>Compatible with 1080p, 720p, D1 and etc.
>HDMI, VGA output up to 1080p, 1 TV
>8/16/16/16ch alarm in & 3/6/6/6ch relay out, RS485, RS232
>8 SATA, 1 eSATA, 4 USB, 2 RJ45(1000M)
>Incoming bandwidth:256Mbps
Features
>Up to 8/16/32/64 channel cameras connection
>H.264/MJPEG dual codec decoding
>Max 256Mbps incoming bandwidth
>HDMI / VGA/TV simultaneous video output up to 1080P live view
>8/16/32 channel synchronous realtime preview, GRID interface
>Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotek and etc.
>ONVIF Version 2.2 conformance
>3D intelligent positioning with Dahua PTZ camera
>Support 8 SATA HDDs up to 32TB,1 eSATA up to 16TB, 4 USB2.0
>Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
Technical Specifications
|
Model |
NVR7808 |
NVR7816 |
NVR7832 |
NVR7864 |
|
System |
|
Main Processor |
Dual-core embedded processor |
|
Operating System |
Embedded LINUX |
|
Video & Audio |
|
IP Camera Input |
8 channel |
16 channel |
32 channel |
64 channel |
|
Two-way Talk |
1 channel input, 1 channel output, BNC |
|
Display |
|
Interface |
1 HDMI, 1 VGA, 1TV |
|
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 & etc. |
|
Display Split |
1/4/8/9 |
1/4/8/9/16 |
1/4/8/9/16/25/36 |
1/4/8/9/16/25/36 |
|
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
|
Ethernet |
2 RJ-45 ports (10/100/1000Mbps) |
|
Network Function |
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.) |
|
Max. User Access |
128 users |
|
Smart Phone |
iPhone, iPad, Android, Windows Phone |
|
Storage |
|
Internal HDD |
8 SATA ports (8HDDs or 6HDDs+1CD/DVD-RW), up to 32TB, Raid (redundancy) |
|
External HDD |
1 eSATA port |
|
Auxiliary Interface |
|
USB |
4 ports (2 Rear), USB2.0 |
|
RS232 |
1 port, For PC communication & Keyboard |
|
RS485 |
1 port, For PTZ control |
|
General |
|
Power Supply |
AC 100V~240V, 50/60 Hz |
|
Power Consumption |
75W (without HDD) |
|
Working Environment |
-10°C~+55°C / 10%~90%RH / 86~106kpa |
|
Dimension
(W×D×H) |
2U, 440mm×460mm×89mm |
|
Weight |
6KG (without HDD) |  |
