Features
>1/4” 1Megapixel CMOS
>H.264 & MJPEG dual-stream encoding
>Max 25/30fps@720P(1280×720)
>DWDR, Day/Night, 3DNR, Auto iris, AWB, AGC, BLC
>Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
>3.6mm fixed lens
>PIR sensor range 6m (for KW12(W) only)
Technical Spcifications
|
Model |
IPC-KW10(W) |
IPC-KW12(W) |
|
Camera |
|
Image Sensor |
1/4” 1Megapixel CMOS |
|
Effective Pixels |
1280(H)x720(V) |
|
Scanning System |
Progressive |
|
Electronic Shutter Speed |
Auto/Manual, 1/3(4)~1/10000 |
|
Min. Illumination |
0.1lux/F1.2（color） |
|
S/N Ratio |
More than 50dB |
|
Video Output |
N/A |
|
Camera Features |
|
Max. LEDs Length |
10m |
|
Day/Night |
Auto(ICR) / Color / B/W |
|
Backlight Compensation |
BLC / HLC / DWDR |
|
White Balance |
Auto/Manual |
|
Gain Control |
Auto/Manual |
|
Noise Reduction |
3D |
|
Privacy Masking |
Up to 4 areas |
|
Lens |
|
Focal Length |
3.6mm |
|
Max Aperture |
F1.8 |
|
Focus Control |
Manual |
|
Angle of View |
70° |
|
Lens Type |
Fixed Lens |
|
Mount Type |
Board-in Type |
|
Video |
|
Compression |
H.264/MJPEG |
|
Resolution |
720P(1280x720)/D1/CIF |
|
Frame Rate |
Main Stream |
720P(1~25/30fps) |
|
Sub Stream |
D1/CIF(1 ~ 25/30fps) |
|
Bit Rate |
H.264: 56K ~ 8192Kbps |
|
Audio |
|
Compression |
G.711a / G.711u / PCM |
|
Interface |
Built-in Mic |
Built-in Mic/ Speaker |
|
Network |
|
Ethernet |
RJ-45 (10/100Base-T) |
|
Wi-Fi |
Wi-Fi (for KW10/12W only) |
|
Protocol |
IPv4/IPv6, HTTP, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour |
|
ONVIF |
ONVIF Profile S |
|
Max. User Access |
10 users |
|
Smart Phone |
iPhone, iPad, Android, Windows Phone |
|
Auxiliary Interface |
|
Memory Slot |
N/A |
64GB |
|
RS485 |
N/A |
|
Alarm |
N/A |
|
PIR Sensor Range |
N/A |
Up to 6m |
|
General |
|
Power Supply |
DC12V |
|
Power Consumption |
<4W |
|
Working Environment |
-30°C~+60°C, Less than 95%RH |
|
Ingress Protection |
N/A |
|
Vandal Resistance |
N/A |
|
Dimensions(W×D×H) |
66.6mm×99.5mm×131.2mm |
|
Weight |
0.35Kg (0.4kg with bracket) |  |
