Features
>1/4” 1Megapixel CMOS
>H.264 encoding
>Max 25fps@720P(1280×720)
>DWDR, Day/Night, 3DNR, Auto iris, AWB, AGC, BLC
>Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
>Wi-Fi support
>Micro SD card，DC5V
Specifications
|
Model |
IPC-C10 |
|
Camera |
|
Image Sensor |
1/4” 1Megapixel CMOS |
|
Effective Pixels |
1280(H)x720(V) |
|
Scanning System |
Progressive |
|
Electronic Shutter Speed |
Auto/Manual, 1/3(4)~1/10000 |
|
Min. Illumination |
0.01lux/F2.0(color),0lux/F2.0(IR on) |
|
S/N Ratio |
More than 50dB |
|
Video Output |
N/A |
|
Camera Features |
|
Max. LEDs Length |
5m |
|
Day/Night |
Auto(ICR) / Color / B/W |
|
Backlight Compensation |
BLC / HLC / DWDR |
|
White Balance |
Auto/Manual |
|
Gain Control |
Auto/Manual |
|
Noise Reduction |
3D |
|
Lens |
|
Focal Length |
3.3mm |
|
Max Aperture |
F2.0 |
|
Focus Control |
Manual |
|
Angle of View |
56.7° |
|
Lens Type |
Fixed Lens |
|
Mount Type |
Board-in Type |
|
Video |
|
Compression |
H.264 |
|
Resolution |
720P(1280x720)/D1/CIF |
|
Frame Rate |
Main Stream |
720P(1~25/30fps) |
|
Bit Rate |
H.264: 8Kbps～2Mbps |
|
Audio |
|
Compression |
AAC |
|
Interface |
Built-in Mic/Speaker |
|
Network |
|
Ethernet |
NA |
|
Wi-Fi |
Wi-Fi(IEEE802.11b/g/n)
30m(open field) |
|
Protocol |
IPv4/IPv6, HTTP, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS,FTP, QoS, |
|
Compatibility |
ONVIF CGI |
|
Max. User Access |
10 users |
|
Smart Phone |
iPhone, iPad, Android, Windows Phone |
|
Auxiliary Interface |
|
Memory Slot |
Micro SD, up to 64GB |
|
RS485 |
N/A |
|
Alarm |
N/A |
|
PIR Sensor Range |
N/A |
|
USB |
Micro USB |
|
General |
|
Power Supply |
DC 5V |
|
Power Consumption |
<3W |
|
Working Environment |
-20°C~+45°C, Less than 95%RH |
|
Ingress Protection |
N/A |
|
Vandal Resistance |
N/A |
|
Dimensions(W×D×H) |
Φ65mmx85mmx 20mm |
|
Weight |
75g |  |
