Features
> Full HD standalone network video decoder for TV wall monitoring system > Support multiple devices: Network camera, DVR, NVS > H.264/MPEG-4 dual codec video decoding > Support multiple resolution decoding: QCIF/CIF/2CIF/ HD1/D1/720P/1080P > Up to 1080P display output & various interface: HDMI, VGA and BNC > Support various split-window modes > Alarm input/output, RS232, RS485 > Powerful 1000M Ethernet interface > WEB GUI interface for easy setup and control > Standard 19-inch 1U chassis for easy installation
Technical Specifications
Model |
NVS0104DH |
NVS0404DH |
System |
Main Processor |
Dual-core embedded processor |
Operating System |
Embedded LINUX |
Video |
Video Output |
HDMI x 1, VGAI x 1, BNC x 1 |
HDMI x 4, VGAI x 4, BNC x 4 |
Video Standard |
H.264 / MPEG4 |
Video Decoding |
D1: 16 channel, 2MBps 720P: 8 channel, 4MBps 1080P: 4 channel, 8MBps |
D1: 28 channel, 2MBps 720P: 14 channel, 4MBps 1080P: 7 channel, 8MBps |
Video Frame Rate |
PAL: 1~25fps, NTSC: 1~30fps |
Audio |
Audio Output |
HDMI x 1, BNC(200~3000mV, 5KΩ) x 1 |
HDMI x 4, BNC(200~3000mV, 5KΩ) x 4 |
Audio Standard |
PCM / G711 |
Voice Intercom |
1 channel input, BNC(200-2800mV, 30KΩ), 1 channel output, BNC(200-3000mV, 5KΩ) |
Display |
Display Split |
1/4/9/16 |
Display 1: 1/4/9/16 Display 2~4: 1/4 |
Display Resolution |
1280 x 1024,1280 x 720,1920 x 1080 |
Tour Display |
Support, 1/4/9 display split |
Network |
Ethernet |
RJ-45 port (10/100M/1000M) |
Network Protocol |
HTTP, TCP/IP, UDP, NTP, DHCP, DNS |
Remote Operation |
System setting , Playback, Upgrade, Log information |
Alarm |
Alarm Input |
16 channel |
Alarm Output |
8 channel relay output (30VDC/1A, 125VAC 0/5A activation output) |
Trigger Events |
Tour, Alarm |
Auxiliary Interface |
USB Interface |
USB2.0 port |
RS232 |
Keyboard, PC communication |
RS485 |
2 duplex RS485 ports |
Working Environment |
Power Supply |
DC12V,3.3A |
DC12V, 5.0A |
Power Consumption |
Max 10W |
Max 40W |
Working Environment |
0 ~+55°C / 10~90%RH / 86~106kpa |
Dimension |
1U, 440mm x 300mm x 42mm(W×D×H) |
Weight |
3.00KG |
3.50 KG |
|
