Features
> 4.3” TFT LCD screen, with outstanding effect.
> Easy to use with big buttons.
> Color Video phone, support hand-free calls.
> Support monitoring, video talk, unlock function
> Support Information check, can receive Message from guard office
> Directly notice to guard office for emergency
> Compatible to up to 4 security sensors( burglar, fire, gas leakage, etc)
Specifications
|
Mode |
VTH1200CS |
|
System |
Main Processor |
NEC MCU |
|
Operation Interface |
Simple OSD message |
|
Input Device |
Mechanical keys, 5 |
|
Video |
Video Input |
1-ch CVBS analog video |
|
Video Display |
4.3” color LCD, resolution: 480*272 |
|
Monitoring |
Support monitoring with monitor button |
|
Audio |
Audio Input |
1-ch microphone input (Omni-directional electrets)
1-ch handset pickup input |
|
Audio Output |
1-ch loudspeaker output
1-ch handset speaker output |
|
Bidirectional Talk |
1-ch bidirectional talk, two way |
|
Network Function |
Net Control |
Monitor & Unlock |
|
Call management center for emergency |
|
RS485 bus |
|
Remotely upgrade |
|
Interface |
Net Interface |
RJ45 (non-Ethernet) plug connected with distributor, including power supply, AV and control signal |
|
RS485 |
Bus control and software upgrading |
|
DC Power |
24V |
|
System Upgrading |
Remote network upgrading |
|
General |
Power |
24V |
|
Power Consumption |
Standby ≤1W?max ≤5W |
|
Temperature |
-5℃－＋55℃ |
|
Humidity |
20%－90% |
|
Dimensions |
220.1mm*156.3mm*12.1mm (L*W*T); |
|
Weight |
0.45Kg |
|
Installation Method |
Installed on 86 box sheet metal bracket |  |
